DeviceNet Information A-17
Publication 198-UM001B-EN-P September 2001
Discrete Input Point Object — Class ID (08hex)
Multiple instances of the Discrete Input Object are supported. All instances contain the
following attributes:
Discrete Output Point Object — Class ID (09hex)
Table A.22 Discrete Input Object Class Attributes
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
2 Get Max Instances UINT 0…64
Table A.23 Discrete Input Object Instance Attributes
Attribute ID Access Rule Name Data Type Value
3 Get Value BOOL Input point Value.
0 = OFF
1 = ON
5 Get/Set Off_On Delay UINT 0 µs
2000 µs
4000 µs
8000 µs
16000 µs
6 Get/Set On_Off Delay UINT 0 µs
2000 µs
4000 µs
8000 µs
16000 µs
Table A.24 Discrete Input Object Common Services
Service Code Implemented for: Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Table A.25 Discrete Output Object Class Attributes
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instances UINT 0…80
