A-12 DeviceNet Information
Publication 198-UM001B-EN-P September 2001
Input Assembly Instance 103
This assembly reserves a byte (8 bits) for every module on the system — regardless of
whether it has any inputs. The size of the assembly equals the number of modules present
plus five status bytes. This is the default assembly for the 198-DNGmodules when there are
more than six I/O modules. The following is the example data layout. The status and error
codes follow on pages A-15 and A-16.
5 198-IB2XOB1 198-IB2XOW1
— — Input 2 Input 1 — — Input 2 Input 1
6 198-IA2 198-IB2S
— — Input 2 Input 1 Open Short Input 2 Input 1
7 198-IB2XOB5S
— — — — — — Input 2 Input 1
Table A.17 Input Assembly Instance 103
Slot Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 I/O
Module
Status 8
I/O
Module
Status 7
I/O
Module
Status 6
I/O
Module
Status 5
I/O
Module
Status 4
I/O
Module
Status 3
I/O
Module
Status 2
I/O
Module
Status 1
1 I/O
Module
Status 16
I/O
Module
Status 15
I/O
Module
Status 14
I/O
Module
Status 13
I/O
Module
Status 12
I/O
Module
Status 11
I/O
Module
Status 10
I/O
Module
Status 9
2 Module Error Number
3 Error Code
1 4 — — — — — — Input 2 Input 1
2 5 — — — — — — Input 2 Input 1
3 6 — — — — Open Short Input 2 Input 1
4 7 — — — — — — — —
5 8 — — — — — — Input 2 Input 1
6 9 — — — — — — Input 2 Input 1
Table A.16 Input Assembly Instance 101 (Continued)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
