3-29
Publication 198-UM001B-EN-P September 2001
X = Reserved
Table 3.G Instance 104 Data Format for Output Assembly
Module Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1 0 X X X X X X Output 2
Value Output 1
Value
2 1 X X X X X X X X
3 2 X X X X X X X Output 1
Value
4 3 X X X X X X X Output 1
Value
5 4 X X X X X X X X
6 5 X X X X X X X X
Table 3.H I/O Output Assembly Data Attribute Mapping
Data Component Name Class Instance
Number Attribute
Name Number Name Number
Module 1 Output 1 Discrete output point 09hex 1 Value 3
Module 1 Output 2 Discrete output point 09hex 2 Value 3
Module 3 Output 1 Discrete output point 09hex 3 Value 3
Module 4 Output 1 Discrete output point 09hex 4 Value 3
