A-10 DeviceNet Information

Publication 198-UM001B-EN-P September 2001

Output Assembly Instance 100

This assembly reserves 4 bits (a nibble) for every output module on the system (except for the
two drive modules). This is the only output assembly available for the Series A
198-DN/DNG modules. The following table illustrates Instance 100.

Output Assembly Instance 102

This output assembly reserves a byte for every module available on the system, regardless of
type. The size of the assembly will determine the number of bytes. This is the default
assembly for the 198-DNG module if there are more than six modules.

Table A.13 Output Assembly Instance 100

Byte

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

0

198-IB2XOB1

198-IB2XOW1

Output 2

Output 1

Output 2

Output 1

1

198-IB2XOB2S

198-OW2-G4

Output 2

Output 1

Output 2

Output 1

2

198-IB2XOB2S

Output 5

Output 4

Output 3

Table A.14 Output Assembly Instance 102

Slot

Byte

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

1

0

Output 1

2

1

Output 1

3

2

4

3

Output 2

Output 1

5

4

6

5

Output 5

Output 4

Output 3

Output 2

Output 1
