OPERATOR’S STATION
169304
33
Rev. C
ENGINE RUNNING/HEADER ENGAGED
DRAPER HEADER/INDEX SWITCH OFF
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line) DESCRIPTION
#####.# ENGINE HRS Total Engine Operating Time.
#####.# HEADER HRS Total Header Operating Time.
##.# ACRES/HOUR
##.# HECTARES/HOUR
(If Metric)
Actual Cutting Rate In Acres (Hectares)/Hour.
###.# SUB ACRES
###.# SUB HECTARES
(If Metric)
Area Cut Since Last Reset.
###### TOTAL ACRES
###### TOTAL HECT
(If Metric)
Total Area Cut By Machine.
##.## REEL MPH or RPM
(Optional)
##.## REEL KPH
(If Metric)
##.## REEL SENSOR
(If Sensor Disabled)
Reel Peripheral Speed in miles per hour. Reel Speed
in rpm.
##.# DRAPER SPEED Draper Speed (0.0-10.0).
#### KNIFE SPEED
(Optional)
#### KNIFE SENSOR
(If Sensor Disabled)
Knife Speed In Strokes Per Minute.
##.# HEADER HEIGHT
##.# HEADER SENSOR
(If Sensor Disabled)
Distance Setting (00.0-10.0) Between Cutterbar &
Ground.
##.# HEADER ANGLE
(Optional)
##.# HEADER SENSOR
(If Sensor Disabled)
Angle Setting (00.0-10.0) Header Relative To
Ground.
FUEL LEVEL |■■■■|■■■■| Level of Fuel In Tank.
ENGINE TEMP ### ° F
ENGINE TEMP ### °C
(If Metric)
Engine Coolant Temperature.
##.# VOLTS Engine Electrical System Operating Voltage.
SCROLL
SUB-MENU (Lower Line Only)
#### KNIFE SPEED(Optional)
##.## REEL RPM
##.# DRAPER SPEED
FUEL LEVEL |■■■■|■■■■|
ENGINE TEMP ### ° F
ENGINE TEMP ### °C (If Metric)
##.# HEADER HEIGHT
Displays Sub-Menu After 2-3 Seconds. Press
SELECT to cancel.
Scroll Through Sub-Menu Display with CDM Switch
KNIFE SPD OVERLOAD
(Lower Line) Knife Speed Is Less Than Programmed Set-Point.
