Operator’s station, 16 windrower controls – MacDon M100 SP Operators Manual User Manual
Page 28
OPERATOR’S STATION
169304
26
Rev. C
5.16 WINDROWER CONTROLS
HAZARD WARNING LIGHTS
Activates Signals On Windrower and Header
Push On – Push Off
FAST
SLOW
GROUND SPEED LEVER (GSL)
Controls Speed and Direction of Movement
F – Forward
N – Neutral
N-DETENT – Engages Neutral Interlock and Applies
Park Brake When Steering Locked In Center
R - Reverse
N-DETENT
TURN SIGNALS
Activates Turn Signals On Windrower and Header
Push On – Push Off
REVERSE
