CDM/WCM FAULT CODES
169304
185
Rev. C
E 1
E 2
R T C H N O T A L L O W E D Return To Cut activated with the header off.
E 3
E 4
E 5
E 6
T E M P G A U G E S H O R T Wiring / connection problem.
E 7 S P E E D S T I C K S H O R T Wiring / connection problem.
E 8 H E A D E R E N A B L E S H O R T Wiring / connection problem.
E 9
E 10
C D M I N T E R N A L E R R O R Internal hardware or software problem.
E 11 C D M P O W E R U P CDM Module did not power up correctly.
E 12
E 13
F U E L S O L E N O I D WCM Fuel solenoid output fault detected.
E 14
E 15
K N I F E D R I V E P W M V 8 Knife drive - PWM solenoid drive fault detected.
E 16 D R A P E R D R V P W M V 9 A Draper Drive - PWM solenoid drive fault detected.
E 17 R E E L D R I V E P W M V 9 B Reel Drive - PWM solenoid drive fault detected.
E 18
E 19
E 20
E 21
E 22
E 23
E 24
E 25
E 26
E 27
E 28
T I L T R E T R A C T V 2 B Tilt retract solenoid V2B fault detected.
E 29 T I L T E X T E N D V 2 A Tilt extend solenoid V2A fault detected.
E 30 4 W A Y V A L V E V 6 4 Way valve V6 fault detected.
E 31 B Y P A S S V A L V E V 1 Bypass valve V1 fault detected.
E 32 H E A D E R U P / D O W N V 4 A Header up / down solenoid V4A fault detected.
E 33 S C R E E N C L E A N E R S Screen cleaner output fault detected (shorted or open).
E 34 R I G H T S T O P L A M P Right stop lamp output fault detected (shorted or open).
E 35 L E F T S T O P L A M P Left stop lamp output fault detected (shorted or open).
E 36 R I G H T T U R N L A M P Right turn lamp output fault detected (shorted or open).
E 37 L E F T T U R N L A M P Left turn lamp output fault detected (shorted or open).
E 38 M A I N D R I V E V 1 0 Main header drive solenoid V10 fault detected.
E 39
E 40
H I G H R A N G E V 5 A High range solenoid V5A fault detected.
E 41 R E E L A F T V 2 B Reel aft solenoid V2B fault detected.
E 42 R E E L F O R E V 4 D Reel fore solenoid V4D fault detected.
E 43 R E E L U P / D O W N V 4 B Reel up / down solenoid V4B fault detected.
E 44
E 45
E 46
S E N S O R V O L T S H I G H Sensor voltage output high.
E 47 S E N S O R V O L T S L O W Sensor voltage output low.
E 48
E 49
E 50
B A T T + O U T O F R A N G E System voltage above 16.5 VDC.
E 51
E 64
E 65
E 66
# # . # L O W V O L T S Low system voltage <11.5 VDC
E 67 T R A N S O I L P R E S S U R E Drive charge pressure low
E 68 T R A N S O I L T E M P Trans oil temp >221 deg F.
E 69
E 70
E 71
L O W H Y D R A U L I C O I L Low hydraulic oil level sensor tripped
E 72 # # . # H I G H V O L T S System voltage above
E101 S P I E R R O R J1939 Can error
E102 C A N E R R O R J1939 Can error
E103 E E P R O M R E A D E R R O R Internal error
E104 E E P R O M W R I T E E R R O R Internal error
E105 T E M P S E N S O R E R R O R Internal temperature sensor error.
E N G I N E O I L P R E S S U R E Engine oil pressure warning.
E N G I N E T E M P E R A T U R E Engine coolant temperature warning.
C A N B U S S E R R O R
N O O P E R A T O R Operator not detected in seat (~3 second delay before message)
N O H E A D E R No header ID detected - not hooked up or wiring error.
D I S E N G A G E H E A D E R Header engage switch on when ignition turned on.
S F C Engine code configuration (Canbus)
C E N T E R S T E E R I N G GSL or Pintal switches not closed with the key on / engine off.
N O T I N P A R K GSL or Pintal switches not closed with the key on / engine off.
CDM / WCM FAULT CODES
MISC INFORMATION / ERROR CODES
Error codes E52 to E63 not allocated
Error codes E73 to E100 not allocated
