Mechanical installation
Assembly in push−through technique (thermal separation)
5
l
75 EDS700ACBA EN 4.0
5.3.6 Assembly in push−through technique (thermal separation)
)
Note!
The installation must ensure the required tightness.
For this purpose, the mounting plate with the required cutouts must have a
sufficient rigidity against the seal.
Overview of the mechanical requirements of the mounting position:
Requirements
Cutouts
Tolerance ± 0.5 mm
Corner radius R 1 ... 2 mm
Evenness to the seal 0.5 mm
Fixing holes
Tolerance ± 0.25 mm
Seal Use thread sealant
Bar reinforcement (suggestion)
Flat material 5 * 20 * 400 mm
Power loss
Type P
V1
[W] P
V2
[W]
E70ACPSD0304x 60 20
E70ACMSD0054xx1xxx 30 20
E70ACMSD0104xx1xxx 50 30
E70ACMSD0204xx1xxx 100 30
E70ACMSD0054xx2xxx 60 30
E70ACMSD0104xx2xxx 100 50
E70ACPSD0604x 130 30
E70ACMSD0324xx1xxx 160 50
E70ACMSD0484xx1xxx 230 70
E70ACMSD0644xx1xxx 310 80
E70ACMSD0204xx2xxx 200 60
E70ACMSD0324xx2xxx 310 70
P
V1
separated power loss, to be dissipated via heatsink
P
V2
Power loss remaining in the control cabinet
