Technical data
Rated data
Axis modules
4
l
36 EDS700ACBA EN 4.0
4.2.4 Axis modules
Basics of the rated data
Mains Voltage Voltage range Frequency range Voltage
U
DC
[V]
Voltage range
U
DC
[V]
Frequency range
f [Hz]
2/PE DC 565 455 − 0 % ... 620 + 0 % −
2/PE DC 675 540 − 0 % ... 745 + 0 % −
Input data
Voltage Frequency current [A] Number of
phases
[V] [Hz] up to +40 °C

up to +55 °C

E70ACMSx0054xx1xxx 565/675 DC 5.0/4.9 3.1/3.1 2
E70ACMSx0104xx1xxx 565/675 DC 9.3/9.2 5.8/5.8 2
E70ACMSx0204xx1xxx 565/675 DC 18.7/18.5 11.7/11.6 2
E70ACMSx0324xx1xxx 565/675 DC 29.8/29.7 18.6/18.6 2
E70ACMSx0484xx1xxx 565/675 DC 44.6/44.5 27.9/27.9 2
E70ACMSx0644xx1xxx 565/675 DC 59.2/59.1 37.0/37.0 2
E70ACMSx0054xx2xxx 565/675 DC 9.3/9.2 5.8/5.8 2
E70ACMSx0104xx2xxx 565/675 DC 18.7/18.5 11.7/11.6 2
E70ACMSx0204xx2xxx 565/675 DC 37.0/36.9 23.1/23.0 2
E70ACMSx0324xx2xxx 565/675 DC 59.2/59.1 37.0/37.0 2
 Temperature in the control cabinet
