Mechanical installation

Dimensions

Assembly in standard built−in technique

5

l

67

EDS700ACBA EN 4.0

5.3.2

Assembly in standard built−in technique

i700S00x

c

c1

c2

c3

d1

d2

d3

j11

j21

g1

g2

g3

[A]

[mm]

E70ACPSE0304x

30

50

25

25

−

10

10

390

90

70

6

10

15

E70ACMSE0054xx1xxx

5

E70ACMSE0104xx1xxx

10

E70ACMSE0204xx1xxx

20

E70ACMSE0054xx2xxx

2*5

E70ACMSE0104xx2xxx

2*10

E70ACPSE0604x

60

50

E70ACMSE0324xx1xxx

32

E70ACMSE0484xx1xxx

48

E70ACMSE0644xx1xxx

64

E70ACMSE0204xx2xxx

2*20

E70ACMSE0324xx2xxx

2*32
