Accessories (overview)
Terminals
11
l
143 EDS700ACBA EN 4.0
11.6 Terminals
To the devices of the i700 servo inverter product series, coordinated terminal accessory kits
are assigned. These kits must be ordered separately.
Accessory kits
E70ACMSx0054xA1xxx
E70AZEVK001 E70ACMSx0104xA1xxx
E70ACMSx0204xA1xxx
E70ACMSx0324xA1xxx
E70AZEVK003 E70ACMSx0484xA1xxx
E70ACMSx0644xA1xxx
E70ACMSx0054xA2xxx
E70AZEVK002
E70ACMSx0104xA2xxx
E70ACMSx0204xA2xxx
E70AZEVK004
E70ACMSx0324xA2xxx
E70ACPSx0304x E70AZEVK005
E70AZEVK007
(for parallel connection) E70ACPSx0604x E70AZEVK006
) Kit E70AZEVK...
...001 ...002 ...003 ...004
X1 SIB, GS,
SIA 1 (A) 2 (A, B) 1 (A) 2 (A, B)
X2 GD, DI2,
DI1 1 (A) 2 (A, B) 1 (A) 2 (A, B)
X3 GE, 24E 1 1 1 1
X4/X5 EtherCAT 1 1 1 1
X105 GE, 24E 1 1 1 1
X106 BD2, BD1 1 (A) 2 (A, B) 1 (A) 2 (A, B)
X108 U, V, W,
PE 1 (A), 4 mm 2 1 (A), 4 mm 2 1 (A), 16 mm 2 1 (A), 4 mm 2
X107 U, V, W,
PE − 1 (B), 4 mm 2 − 1 (B), 4 mm 2
X104 T2, T1 1 (A) 2 (A, B) 1 (A) 2 (A, B)
 " 1 ( « 50) 1 ( « 50) 1 ( « 100) 1 ( « 100)
‚ 2 1 2
ƒ 3 − − 1 2
„ − 1 1 1 1
