Technical data
General data and operating conditions
4
l
28 EDS700ACBA EN 4.0
Requirements on the motor cable
Capacitance per unit length
£ 2.5 mm 2 /AWG 14 C
Core/core
/C
Core/shield
< 75/150 pF/m
³ 4 mm 2 /AWG 12 C
Core/core
/C
Core/shield
< 150/300 pF/m
Electric strength
VDE 0250−1 U
0
/U = 0.6/1.0 kV
(U 0 = r.m.s. value external − conductor/PE,
U = r.m.s. value − external conductor/external conductor)
UL U ³ 600 V
(U = r.m.s. value external conductor/external conductor)
Mounting conditions
Mounting place In the control cabinet
Mounting position Vertical
Free space
At the top/at the
bottom
³ 80 mm / ³ 120 mm
Observe the device−related
notes on mounting.
On the sides Side−by−side mounting without
any clearance
