Safety engineering
Technical data
l
133
EDS700ACBA EN 4.0
10.6
Technical data
Supply
The inputs are isolated and designed for a low−voltage supply through a safely separated
power supply unit (SELV/PELV) of 24 V DC. P/N switching input signals and test pulses
£ 1 ms are permissible.
Active sensors are directly wired to the X1 terminal strip.
Passive sensors are wired to the X1 terminal strip via a switching device. The switching
device must comply with the required control category of the application.
There is no monitoring for short circuits.
Terminal X1
Specification
[Unit]
min.
typ.
max.
The input channels comply with the IEC 61131−2 standard, type 1.
SIA, SIB
Low signal
V
−3
0
5
High signal
V
15
24
30
Input capacitance at switch−off
nF
3
Input delay (tolerated test pulse)
ms
1
Switch−off time
ms
5
Running time
ms
1
Input current
mA
2
15
Input capacitance at switch−on
nF
100
Test pulses permissible at intervals of
ms
10
Polarity reversal protection
When polarity is reversed: no function
and no destruction.
GS
Ground for SIA/SIB
Truth table
Safe input / channel
Controller
SIA
SIB
Description of device status
Enable
0
0
"Safe torque off" activated
0
0
1
0
1
0
0
1
1
Drive active
1
