Chapter 5 Troubleshooting
80 Avaya X330WAN User’s Guide
Degraded Mins
6 Errored Secs, 1 Bursty Err Secs, 5 Severely Err
Secs, 0 Unavail Secs
E1 2 is administratively down.
For information on the fields in the show controllers command output, refer to
Chapter 6: X330WAN CLI Commands.
To monitor the state of the X330W-2USP ports, use the
show interface command.
For the output from the show interface command, see Chapter 6: X330WAN CLI
Commands.
Handling E1/T1 Alarms
Alarms are reported by the LEDs on the X330W-2DS1 and via the CLI. When an
alarm condition is detected by X330W-2DS1, it sends a signal to all E1/T1 devices
connected to it. Alarms can be categorized as one of the following:
•
Local Alarm Indication - Generated by the X330W-2DS1 as a result of a line
status problem sensed by the X330W-2DS1.
• Remote Alarm Request - Received by the X330W-2DS1 from the remote
module.
The following table provides a list of alarms, the type of alarm, and the alarm
condition on the module from which the alarm originates.
More detailed information about alarms can be obtained using the
show controllers CLI command. For more information, refer to "Monitoring
Traffic" on page 79.
The following sections discuss the different types of alarms, how each alarm type is
indicated, and possible corrective actions to end the alarm.
Table 5.1 Alarms
Alarm (E1/T1) Alarm Type Originating Alarm
LOS/LOS Local Alarm Indicator N/A
LOF/Red Local Alarm Indicator N/A
High BER/Major Local Alarm Indicator N/A
Low BER/Minor Local Alarm Indicator N/A
RAI/Yellow Remote Alarm Request LOS, LOF, BER, AIS
AIS/Blue Remote Alarm Request Maintenance request
