EMU Generated Condition Reports
175 Enterprise Virtual Array 3000 User Guide
EMU Conditions
The format of an EMU condition report is 0.7.01.ec, where:
■ 0.7. is the EMU element type number
■ 01. is the two-character EMU element number
■ ec is the error code
Note: There is only one EMU in a drive enclosure. Therefore, the element number is
always 01.
Resetting the EMU
In some cases, the only corrective action for an EMU error is to replace the EMU.
Call your HP authorized service representative if this action is required. Another
option is to reset the EMU using the following procedure.
1. Firmly grasp the EMU mounting handle and pull the EMU partially out of the
enclosure.
Note: You do not need to remove the EMU from the enclosure or disconnect the cables.
Avoid putting any strain on the cables or connectors.
2. Wait 30 seconds, and then push the EMU in and fully seat the element in the
backplane. The EMU should display any enclosure condition report within
two minutes.
07.01.01 CRITICAL Condition
—
EMU Internal Clock
There is an internal EMU clock error that will remain active until the problem is
corrected.
Complete the following procedure to correct this problem.
1. Record all six characters of the condition report.
2. Reset the EMU.
3. If resetting the EMU did not correct the problem, replace the EMU.
4. Observe the EMU to ensure the error is corrected.
