Storage System Hardware Components
101 Enterprise Virtual Array 3000 User Guide
.
Error Condition Reporting
The EMU constantly monitors enclosure and element operation and notifies you
of conditions that could affect operation. When an error condition is detected, the
following action is taken:
■ The EMU alphanumeric display is changed to Er. A condition report has
precedence over all other displays.
■ The audible alarm sounds (if it is not disabled).
■ The error is stored in the error queue.
■ The error is passed to the controllers for processing and display by Command
View EVA.
1 – 5 Enclosures 1 through 5
Figure 45: Enterprise Virtual Array 3000 enclosure numbering
CXO8061B
5
1
4
2
3
