NOTE:
A system shipped from the factory may have a different configuration than the same
system built in the field. For example: The factory will install the graphics card in slot 12 and
add other cards below. In the field, slot 12 may already be occupied by another PCI card. It is
acceptable for the graphics card to be installed in any available Turbo slot.
Notes
Part Number
Load
Order*
Boot
Max
Description (all are PCI cards)
Product
Number
3,8
A4982-66501
1
No
1
Graphics, Graphics Card
A6150A
9
A5838-60001
3
No
Combo
A5838A
10
A5483-60001
4
No
10
ATM 622Mbps MMF Adapter
A5483A
A4926-60001
5
No
10
1000Base SX PCI LAN Adapter
A4926A
A4926-60001
6
No
10
1000Base TX PCI LAN Adapter
A4926A
11
A6092-60001
7
No
HYPERFabric
A6092A
A5846-60001
8
Y
FC Taclite
A5158A
A5486-60001
9
No
10
Praesidium Speed Card
A5486A
1,2,6
A5506-60101
10
No
7/10
4 Port 100Base TX LAN Adapter
A5506A
A5506-60102
10
No
7/10
4 Port 100Base TX LAN Adapter
A5506B
4
A5150-60001
11
Yes
10
Dual Port Ultra 2 SCSI adapter
A5150A
A5149-60001
12
Yes
10
Single Port Ultra 2 SCSI HBA
A5149A
7,5
5063-1322
13
No
10
High Perf 4 Ports Synchronous Adapter
J3526A
A4800-67002
14
Yes
10
FWD SCSI-2 adapter
A4800A
B5509-66001
15
No
10
100Base-T LAN Adapter
A5230A
A3738-60001
16
No
10
10/100Base-T LAN Adapter
A3738A
A3739-60001
17
No
10
Dual FDDI LAN Adapter
A3739A
A5783-60101
18
No
10
Token Ring 4/16/100 Hardware Adapter
A5783A
J3525-60001
19
No
10
Dual Port Synchronous Adapter
J3525A
J3593-60001
20
No
10
64 port Serial MUX system card
J3593A
J3592-60101
21
No
4
8 Port PCI Serial MUX card
J3592A
A6150-60001
22
No
1
Graphics, USB Card
A6150A
12,13
A6150-60003
1
No
1
Pinnacle 2 Graphics
A6150BX
A3686-60001
6
No
10
Hyper Fabric 2 Interconnect
A6386A
14
A5506-60102
10
No
10
Quad Port 10/100B-TX LAN
A5506A
A6749-60001
24
No
10
3.3v 64 Port Terminal MUX
A6749A
A6748-60001
25
No
10
3.3v 8 Port Terminal MUX
A6748A
*In top down order.
Notes:
1.
Card contains a PCI-to-PCI bridge.
2.
Requires PHKL_20123, PHKL_20629 and PHNE_19826 or their superseded equivalents.
3.
Not supported in non-Turbo slots. Install in Turbo slots only.
