created with time information only, or if key creation fails, a dialog box
will prompt you to enter the PRSV key.
If this dialog box appears, go to step 11; otherwise, go to step 13.
11
.
Enter the PRSV key by following the instructions shown in the dialog box.
The PRSV key is required for the HDLM functions to properly operate.
Also, the value of the PRSV key must be unique for each host.
12
.
If the KAPL09128-W message appears, you will need to re-enter the
correct PRSV key.
If a message does not appear, go to the next step.
13
.
The message Select Storage system to be managed. is displayed.
Click the Next button.
In a VCS environment, because an EMC DMX series or EMC CX series LU
cannot be set as an HDLM management-target device, do not select EMC
Symmetrix DMX Series, CLARiiON CX Series. Similarly, because an
HP EVA series LU cannot be set as an HDLM management-target device,
do not select HP StorageWorks EVA Series.
14
.
Follow the instructions shown in the messages that appear in the window.
¢
If a dialog box with the following text appears during installation, and
the Storport Miniport driver is being used as the HBA driver, stop the
HDLM installation. After that, install QFE838894 or a later version of
the Microsoft Storport driver, or install Windows Server 2003 SP1 or
later.
Notes on using a Storport Miniport driver
Read these notes before using a Storport Miniport driver as an
HBA driver.
The file version of the Storport.sys of this system
(Microsoft(R) Storport driver) is n.n.nnnn.n.
When using a Storport Miniport driver as an HBA driver:
Please update the Storport Miniport driver to a Storport.sys
with a file version n.n.nnnn.n or later.
¢
The PRSV key will be registered before the installation finishes. If the
KAPL09131-W message appears, follow the procedure described in
step 16.
¢
Although a message prompting you to restart the host appears after
the installation has finished, a restart is not necessary.
¢
In the last installation window, the following message might be
output:
When you manage a host by using Global Link Manager and
Windows firewall is enabled on that host, execute the
firewall_setup command to allow a firewall exception.
If Global Link Manager will not be used to manage HDLM, you do not
need to take any action.
To manage HDLM with Global Link Manager, register Firewall
exceptions. For details, see Firewall Settings for Managing HDLM by
Using Global Link Manager on page 3-66 .
