APPENDIX
10
157
OPTIFLEX 2200 C/F
www.krohne.com 07/2013 - 4000668002 - HB OPTIFLEX 2200 R02 en
M D 1 DN100 PN10 - Form B1 flange
M E 1 DN100 PN16 - Form B1 flange
M F 1 DN100 PN25 - Form B1 flange
M G 1 DN100 PN40 - Form B1 flange
P D 1 DN150 PN10 - Form B1 flange
P E 1 DN150 PN16 - Form B1 flange
P F 1 DN150 PN25 - Form B1 flange
P G 1 DN150 PN40 - Form B1 flange (for non-Ex devices only)
R E 1 DN200 PN16 - Form B1 flange
R G 1 DN200 PN40 - Form B1 flange (for non-Ex devices only)
ASME B16.5 / ANSI Flanges 4
E 1 A 1¨ 150 lb RF 2
E 2 A 1¨ 300 lb RF 2
G 1 A 1½¨ 150 lb RF
G 2 A 1½¨ 300 lb RF
H 1 A 2¨ 150 lb RF
H 2 A 2¨ 300 lb RF
L 1 A 3¨ 150 lb RF
L 2 A 3¨ 300 lb RF
M 1 A 4¨ 150 lb RF
M 2 A 4¨ 300 lb RF
P 1 A 6¨ 150 lb RF
P 2 A 6¨ 300 lb RF (for non-Ex devices only)
R 1 A 8¨ 150 lb RF
R 2 A 8¨ 300 lb RF (for non-Ex devices only)
JIS B2220 Flanges
G U P 40A JIS 10K RF
H U P 50A JIS 10K RF
L U P 80A JIS 10K RF
M U P 100A JIS 10K RF
P U P 150A JIS 10K RF
R U P 200A JIS 10K RF
Alternative flange faces
2 Form B2, EN 1092-1 (surface roughness must be specified in the order)
3 Form C, EN 1092-1 (Tongue)
4 Form D, EN 1092-1 (Groove)
5 Form E, EN 1092-1 (Male)
6 Form F, EN 1092-1 (Female)
XF20 XF20 XF20 XF20 4 0 0 0 Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow)
