10
APPENDIX
154
OPTIFLEX 2200 C/F
www.krohne.com 07/2013 - 4000668002 - HB OPTIFLEX 2200 R02 en
Adaptor Adaptor Adaptor Adaptor
0 Without
1 BM100A adaptor
2 BM102 adaptor
3 OPTIFLEX 1300 adaptor
Calibration certificate Calibration certificate Calibration certificate Calibration certificate
0 Without
1 Calibration certificate ±3mm (0.12¨)
2 points (coaxial if > 410mm / 16.14¨) 9
2 Calibration certificate ±3mm (0.12¨)
5 points (coaxial if > 1910mm / 75.2¨) 9
3 Calibration certificate ±3mm (0.12¨)
5 points 10
Drawing/TAG Number Drawing/TAG Number Drawing/TAG Number Drawing/TAG Number
0 Without
2 Tag No. stainless steel plate
Extra option Extra option Extra option Extra option
0 Without
1 NACE design
(MR0175 / MR0103 / ISO 15156)
VF20 VF20 VF20 VF20 4 0 Order code Order code Order code Order code
1 Only for the "4...20 mA passive HART" output option
2 For more data, refer to the Technical data section (Approvals and certification)
3 DIP= Dust Ignition Proof
4 For Ø2 mm / 0.08¨ single cable probes only
5 Do not use with double rod and double cable probes
6 Other flange faces are available. Refer to your local supplier for more data.
7 Do not use with double rod, double cable and coaxial probes
8 Flanges with RF faces have a slip on-type design with an anti-blowout feature. Other flange faces are available. Refer to your local
supplier for more data.
9 For liquids only
10For liquids only and not for the coaxial probe. Calibration points for this option are given by the customer.
