8
TECHNICAL DATA
116
OPTIFLEX 2200 C/F
www.krohne.com 07/2013 - 4000668002 - HB OPTIFLEX 2200 R02 en
8.2 Technical data
Converter
INFORMATION!
• The following data is provided for general applications. If you require data that is more
relevant to your specific application, please contact us or your local sales office.
• Additional information (certificates, special tools, software,...) and complete product
documentation can be downloaded free of charge from the website (Download Center).
Measuring system
Application Level and volume measurement of liquids, pastes, powders and granulates
Measuring principle
Construction Compact version: Measuring probe attached directly to a signal converter
Remote version: Measuring probe installed on a tank and connected by a signal
cable (max. length 100 m / 328 ft) to a signal converter
Operating conditions
Ambient temperature -40…+80°C / -40…+176°F
Integrated LCD display: -20...+60°C / -5...+140°F;
if the ambient temperature is not in these limits, the display switches off
Storage temperature -50…+85°C / -60…+185°F
(min. -40°C / -40°F for devices with the integrated LCD display option)
Protection category IP 66/67 equivalent to NEMA type 4X (housing) and type 6P (probe)
Materials
Housing Polyester-coated aluminium or stainless steel (1.4404 / 316L)
Cable entry Plastic; nickel-plated brass, stainless steel
Electrical connections
Power supply (terminals) Terminals output - Non-Ex / Ex i: Terminals output - Non-Ex / Ex i: Terminals output - Non-Ex / Ex i: Terminals output - Non-Ex / Ex i:
12…30 VDC; min./max. value for an output of 22 mA at the terminal
Terminals output - Ex d: Terminals output - Ex d: Terminals output - Ex d: Terminals output - Ex d:
16…36 VDC; min./max. value for an output of 22 mA at the terminal
Current output load Non-Ex / Ex i: Non-Ex / Ex i: Non-Ex / Ex i: Non-Ex / Ex i: R
L
[Ω] ≤ ((U
ext
-12 V)/22 mA). For more data, refer to Minimum power
supply voltage on page 122.
Ex d: Ex d: Ex d: Ex d: R
L
[Ω] ≤ ((U
ext
-16 V)/22 mA). For more data, refer to Minimum power supply
voltage on page 122.
Cable entry M20 × 1.5; ½ NPT
Cable gland Standard: none
Options: M20×1.5 (cable diameter: 6...12 mm / 0.23...0.47¨);
others are available on request
Signal cable - remote version None for non-Ex devices (4-wire shielded cable of max. length 100 m / 328 ft to be
supplied by the customer). Supplied with all Ex-approved devices. For more data,
refer to Remote device data on page 51
Cable entry capacity (terminal) 0.5…2.5 mm²
