Description of hart interface, 10 hart, Menu tree for ams – KROHNE OPTIFLEX 2200 C_F EN User Manual
Page 144: 1 overview ams menu tree (positions in menu tree)
9
DESCRIPTION OF HART INTERFACE
144
OPTIFLEX 2200 C/F
www.krohne.com
07/2013 - 4000668002 - HB OPTIFLEX 2200 R02 en
9.10 HART
®
menu tree for AMS
Abbreviations of the following tables:
•
Opt
Optional, depending on device version and configuration
•
Rd
Read only
•
Cust
Custody lock protection
•
Loc
Local AMS, affects only AMS views
9.10.1 Overview AMS menu tree (positions in menu tree)
Process variables
Measurements
Analog Output
Device Diagnostics
Overview
Fatal Errors
Warnings (Maintenance required)
Warnings (Out of specifications)
Warnings (Function check)
Methods
Access Right
Tests
Calibrate
Threshold Settings
Conversion Table
Master reset
Configure / Setup
Basic Setup
Basic Parameters
Local Display
Application
Analog Output
Output Functions
Output 1
Units
Device
HART
ID
-
Conversion table
