8
TECHNICAL DATA
136
OPTIFLEX 2200 C/F
www.krohne.com 07/2013 - 4000668002 - HB OPTIFLEX 2200 R02 en
Dimensions in mm
Dimensions in inches
Probe end options for cable probes: double cable Ø4 mm/0.15¨
Figure 8-17: Probe end options for cable probes: double cable Ø4 mm/0.15¨
1 Standard counterweight
2 Threaded end
3 Turnbuckle
q
t
q
t
t
r
q
r
s
s
v
w w
Probe end type Dimensions [mm]
q r s t v w
Counterweight 60 - - Ø38 - -
Threaded end 60 157 70 Ø38 - M8
Turnbuckle 60 289 ±46 172 1 Ш38 Ш6 11
1 Minimum length
Probe end type Dimensions [inches]
q r s t v w
Counterweight 2.4 - - Ø1.5 - -
Threaded end 2.4 6.2 2.8 Ø1.5 - M8
Turnbuckle 2.4 11.4 ±1.8 6.8 1 Ш1.5 Ш0.2 0.4
1 Minimum length
