9
DESCRIPTION OF HART INTERFACE
148
OPTIFLEX 2200 C/F
www.krohne.com 07/2013 - 4000668002 - HB OPTIFLEX 2200 R02 en
View Menu
Access rights
Access level Rd
Method Login
Method Entry Code
HART Variables
1 Poll addr / 2 Tag / 3 Hardware rev
Rd
/ 4 Software rev
Rd
/ 5 Descriptor / 6 Date / 7 Message /
8 Manufacturer Rd / 9 Model Rd / Dev id Rd / Universal id Rd / Fld dev rev Rd / Num req preams Rd / Num resp
preams Rd / Write protect Rd / Production number Rd / Final asmbly num Rd / PV is / SV is / TV is / QV is
1 Current Output Calibration is available only if the service password is used
2 Use "Watch Pulses" to monitor the amplitude of the measured pulses
Measurements
Measurements Level Value / Distance Value
Output Level value / Loop curent / % Range
Yt diagram
Diag / Service
Standard Status Device status PV Analog Channel
Saturated / Configuration
changed
Device-specific status Device failures Oscillator Frequency Failure /
Current Output Drift / Sensor
ROM error / Sensor RAM
error / Sensor EEPROM
error / Converter ROM error /
Converter RAM error /
Converter EEPROM error
Sensor No Signal / Sensor
Not Compatible /
Temperature Out of Range /
Measurement Old / Sensor
Voltage Error / Converter
Voltage Error
Reference Pulse Lost / Level
Pulse Lost Error / Interface
Lost Error / Overfill Error /
No Probe Detected
Device Warning (Out of
Specification)
Flange Lost / Leve Lost
Warning / Interface Lost
Warning / Overfill Warning
Info First Start / EpsilonR Calcul
Frozen / EpsilonR Value Low /
EpsilonR Value High /
Temperature out of range for
HMI
Toolbar
Status Bar
Update
