8
TECHNICAL DATA
120
OPTIFLEX 2200 C/F
www.krohne.com 07/2013 - 4000668002 - HB OPTIFLEX 2200 R02 en
Probe options
Single cable
Ø2 mm / 0.08¨
Single cable
Ø4 mm / 0.16¨
Single rod
Ø8 mm / 0.31¨
Measuring system
Application Liquids Liquids and solids
Measuring range 1...40 m / 3.3...131 ft Liquids:
1...40 m / 3.3...131 ft
Solids:
1...20 m / 3.3...65.6 ft
1...6 m / 3.3...19.7 ft
Dead zone This depends on the type of probe. For more data, refer to "Measurement limits" in
this chapter. 1
Measuring accuracy
Accuracy (in direct mode) Standard: Standard: Standard: Standard:
±
10 mm / ±0.4¨, when distance ≤ 10 m / 33 ft;
± 0.1% of measured distance, when distance > 10 m / 33 ft
Optional: Optional: Optional: Optional:
±
3 mm / ±0.1¨, when distance ≤ 10 m / 33 ft;
± 0.03% of measured distance, when distance > 10 m / 33 ft
Accuracy (in TBF mode) ± 20 mm / ±0.8¨
Resolution 1 mm / 0.04¨
Repeatability ± 1 mm / ±0.04¨
Maximum rate of change at 4 mA 10 m/min / 32.8 ft/min
Operating conditions
Min./Max. temperature at the
process connection (also
depends on the temperature
limits of the gasket material.
Refer to "Materials" in this table.)
-50…+300°C /
-58…+572°F
-50…+150°C / -58…+302°F
Pressure -1…40 barg / -14.5…580 psig
Viscosity (liquids only) 10000 mPa.s / 10000 cP
Dielectric constant ≥ 1.8 in direct mode; ≥ 1.1 in TBF mode
Materials
Probe Stainless steel
(1.4404 / 316L)
Stainless steel (1.4401 / 316);
Hastelloy® C-22 (2.4602)
Gasket (process seal) FKM/FPM (-40…+300°C /
-40…+572°F); Kalrez®
6375 (-20…+300°C /
-4…+572°F); EPDM
(-50...+250°C /
-58...+482°F) 2
FKM/FPM (-40…+150°C / -40…+302°F);
Kalrez® 6375 (-20…+150°C / -4…+302°F);
EPDM (-50...+150°C / -58...+302°F) 2
Process connection Stainless steel (1.4404 / 316L); Hastelloy® C-22 (2.4602)
Process connections
Thread For more data on options, refer to Order code on page 149
Flange For more data on options, refer to Order code on page 149
1 These values are correct when the Dynamic Parasite Rejection (DPR) function is on. The DPR function is set to “on” at the factory.
2 Kalrez® is a registered trademark of DuPont Performance Elastomers L.L.C.
