KROHNE OPTIFLEX 2200 C_F EN - Manual (Page 132)

8
TECHNICAL DATA
132
OPTIFLEX 2200 C/F
www.krohne.com 07/2013 - 4000668002 - HB OPTIFLEX 2200 R02 en
Single probes
Figure 8-14: Single probe options
1 Single rod Ø8 mm / Ø0.31¨ (thread and flange versions - segmented probe option shown on the right side)
2 Single cable Ø2 mm / Ø0.08¨ (thread and flange versions)
3 Single cable Ø4 mm / Ø0.16¨ (thread and flange versions)
INFORMATION!
A wide range of counterweights and anchoring solutions are available. For dimensional data,
refer to the pages that follow. For installation data, refer to How to attach probes to the bottom
of the tank on page 23
.
