KROHNE OPTIFLEX 1300C EN - Manual (Page 98)

6
OPERATION
98
OPTIFLEX 1300 C
www.krohne.com 03/2014 - 4000172306 - HB OPTIFLEX 1300 R07 en
6.4.11 How to decrease the length of probes
How to decrease the length of single rod probes
• Measure the length of the rod from the flange facing.
• Cut the rod to the correct length.
• Go to Supervisor > Advanced Setup > Installation Setup > Probe Length
Supervisor > Advanced Setup > Installation Setup > Probe Length Supervisor > Advanced Setup > Installation Setup > Probe Length Supervisor > Advanced Setup > Installation Setup > Probe Length.
• Type in the new value. Push [^ ^ ^ ^].
• Push [>>>>] and [ ] (Esc) at the same time to exit to the "save settings" window.
• Select Save Save Save Save and push [^ ^ ^ ^].
How to decrease the length of cable probes
• Loosen the socket set screws that hold the counterweight.
i Use a 3 mm Allen wrench.
• Remove the counterweight.
• Measure the length of the cable from the flange facing.
i Add the length of the counterweight to get the total probe length. Subtract the length of the
cable engaged in the counterweight. Refer to the diagram after this procedure.
• Cut the cable to the correct length.
• Attach the cable to the counterweight. Tighten the socket set screws.
i Use a 3 mm Allen wrench.
• Go to Supervisor > Advanced Setup > Installation Setup > Probe Length Supervisor > Advanced Setup > Installation Setup > Probe Length Supervisor > Advanced Setup > Installation Setup > Probe Length Supervisor > Advanced Setup > Installation Setup > Probe Length.
• Type in the new value. Push [^ ^ ^ ^].
• Push [>>>>] and [ ] (Esc) at the same time to exit to the "save settings" window.
• Select Save Save Save Save and push [^ ^ ^ ^].
INFORMATION!
This information is for:
• Ø4 mm / 0.16 ¨ double cable,
• single rod,
• Ø2 mm / 0.08 ¨ single cable and
• Ø4 mm / 0.16 ¨ single cable probes only
WARNING!
Do not change the length of coaxial, Ø8 mm / 0.32
¨ single cable and double rod probes. This will
damage the probe. If you change the length of one of these probes, contact the supplier.
INFORMATION!
If you cannot measure the length of the probe, you can use Quick Setup > Setup Mode > Auto
Quick Setup > Setup Mode > Auto Quick Setup > Setup Mode > Auto Quick Setup > Setup Mode > Auto
Probe Length Probe Length Probe Length Probe Length as an alternative. But you must do this procedure when the tank is empty and the
device is installed on the tank.
INFORMATION!
If you cannot measure the length of the probe, you can use Quick Setup > Setup Mode > Auto
Quick Setup > Setup Mode > Auto Quick Setup > Setup Mode > Auto Quick Setup > Setup Mode > Auto
Probe Length Probe Length Probe Length Probe Length as an alternative. But you must do this procedure when the tank is empty and the
device is installed on top of the tank.
