6
OPERATION
74
OPTIFLEX 1300 C
www.krohne.com 03/2014 - 4000172306 - HB OPTIFLEX 1300 R07 en
3B Nozzle Height The height from the tank
connecting flange face/thread
stop to the bottom of the
nozzle.
min-max:
0…60 m / 0…196.86 ft
0.1 m /
0.33 ft
4B Nozzle Diameter The inner diameter of the
nozzle.
min-max:
20…1000 mm /
0.79…39.37 in
100 mm /
3.94 in
5 Settings summary
6 Current changes
must be saved or
cancelled before
proceeding
Save, Cancel 4 Save
A.1.4 A.1.4 A.1.4 A.1.4 Conversion Conversion Conversion Conversion Follow this procedure to set Follow this procedure to set Follow this procedure to set Follow this procedure to set
the device up to display the device up to display the device up to display the device up to display
readings in volume, mass or readings in volume, mass or readings in volume, mass or readings in volume, mass or
user-defined units. user-defined units. user-defined units. user-defined units.
Sub-
menu
Conversion
submenu [Volume] [Volume] [Volume] [Volume]
1 Do you want to use
a free unit?
Select "No". Yes, No
2 Table Length Unit m, cm, mm, inch, ft, Free
Unit
m
3 Please select
Volume / Mass
Select "Volume". Volume
4 Product Type Solid, Liquid
5 Tank Shapes The Wizard adds this step if you
select "Yes" in step 4. This sub-
procedure uses the
information given here to find
the volume. You have to type in
the tank shape, height, width
and length.
... ...
6 Conversion Unit The displayed unit in operator
mode.
m3, L, US gal, GB gal, ft3,
bbl
m3
7 Volume Table A table that converts product
level to product volume.
Push[ ] or [ ] to select a line
and push [>>>>] to change values
automatically supplied by the
device.
Sub-
menu
Conversion
submenu [Mass] [Mass] [Mass] [Mass]
-
1 Do you want to use
a free unit?
Select "No". Yes, No
2 Table Length Unit m, cm, mm, inch, ft, Free
Unit
m
3 Please select
Volume / Mass
Select "Mass". Volume, Mass
4 Do you want to use
density of the
product?
Yes, No
5 Product Density min-max: 0…20000 kg/m3 0
6 Product Type Solid, Liquid
Menu
No. Step Function Function description Selection list Default
