KROHNE OPTIFLEX 1300C EN - Manual (Page 166)

9
DESCRIPTION OF HART INTERFACE
166
OPTIFLEX 1300 C
www.krohne.com 03/2014 - 4000172306 - HB OPTIFLEX 1300 R07 en
9.9.2 AMS menu tree (details for settings)
Configure/Setup
Installation Parameters 1 Installation Type / Tank Height / Probe Length / Sensor Length /
Stillwell Height
Opt / Stillwell Diameter Opt / Blocking Distance /
Snapshot Activation Opt / Nozzle Height / Nozzle Diameter / Tank
Bottom Offset / Reference Offset / Measuring Mode / Gas Er / Product
Er / Detection Delay / Time Constant
Installation Parameters 2 Length Unit / Volume Unit / Mass Unit / Table Length Unit / Conversion
Unit
Opt / Custom. Length Unit / Custom. Length R... / Custom. Conv.
Unit / Product Density
Opt
/ Conversion Flag
Opt
/ Output2 Status
Opt
Output Selection Output Functions Primary Function / Secondary
Function / Tertiary Function /
Fourth Function
Output 1 Output Range / Error Handling /
Error Handling Delay
Output 2 Output Range / Error Handling
Primary Output Setting
(Output1 Loop) 4 mA Setting
Level 4 mA Opt / Distance 4 mA /
Volume 4 mA
Opt
/ Ullage Volume
4 mA Opt / Mass 4 mA Opt / Ullage
Mass 4 mA Opt / Intr Level 4 mA
Opt / Intr Distance 4 mA Opt / Intr
Volume 4 mA Opt / Layer 4 mA Opt /
Layer Vol 4 mA Opt
20 mA Setting Level 20 mA Opt / Distance 20 mA /
Volume 20 mA Opt / Ullage Volume
20 mA Opt / Mass 20 mA Opt /
Ullage Mass 20 mA Opt / Intr Level
4 mA Opt / Intr Distance 4 mA Opt /
Intr Volume 4 mA Opt / Layer 4 mA
Opt / Layer Vol 4 mA Opt
Secondary Output Setting
(Output2 (Passive) Loop) 4 mA Setting
Level 4 mA Opt / Distance 4 mA /
Volume 4 mA Opt / Ullage Volume
4 mA Opt / Mass 4 mA Opt / Ullage
Mass 4 mA
Opt
/ Intr Level 4 mA
Opt
/ Intr Distance 4 mA
Opt
/ Intr
Volume 4 mA
Opt
/ Layer 4 mA
Opt
/
Layer Vol 4 mA Opt
20 mA Setting
Level 20 mA Opt / Distance 20 mA /
Volume 20 mA
Opt
/ Ullage Volume
20 mA
Opt
/ Mass 20 mA
Opt
/
Ullage Mass 20 mA Opt / Intr Level
4 mA Opt / Intr Distance 4 mA Opt /
Intr Volume 4 mA Opt / Layer 4 mA
Opt / Layer Vol 4 mA Opt
Service Parameters 1 Product Separation Cust / Probe Type Cust / Probe Coating Cust /
Counterweight Type Cust / Probe End Pulse Cust / Entire Tank Full Cust /
Entire Tank Empty Cust / Probe End (No Pul... Cust / Length Attenuation
Cust / Mech Attenuation Cust
