TECHNICAL DATA
8
131
OPTIFLEX 1300 C
www.krohne.com 03/2014 - 4000172306 - HB OPTIFLEX 1300 R07 en
Accuracy
Resolution 1 mm / 0.04¨
Repeatability ±1 mm / ±0.04¨
Accuracy (in direct mode) Liquids: Liquids: Liquids: Liquids:
±3 mm / ±0.12¨, when distance < 10 m / 33 ft;
±0.03% of measured distance, when distance > 10 m / 33 ft
Powders: Powders: Powders: Powders:
±20 mm / ±0.8¨
Interface: Interface: Interface: Interface:
±10 mm / ±0.4¨ (εr constant)
Accuracy (in TBF mode) ±20 mm / ±0.8¨ (ε
r
constant)
Minimum layer (interface) 50 mm / 2¨
Reference conditions acc. to EN 60770 Reference conditions acc. to EN 60770 Reference conditions acc. to EN 60770 Reference conditions acc. to EN 60770
Temperature +20°C ±5°C / +68°F ±10°F
Pressure 1013 mbara ±20 mbar / 14.69 psia ±0.29 psi
Relative air humidity 60% ±15%
Operating conditions
Temperature Temperature Temperature Temperature
Ambient temperature -40…+80°C / -40…+176°F
Ex: see supplementary operating instructions or approval certificates
Storage temperature -40…+85°C / -40…+185°F
Process connection temperature Standard Standard Standard Standard
-50…+200°C / -58…+392°F (according to the temperature limits of the gasket
material. Refer to "Material" in this table.)
Ex: see supplementary operating instructions or approval certificates 2
High-Temperature (HT) and High-Temperature / High-Pressure (HT/HP) versions High-Temperature (HT) and High-Temperature / High-Pressure (HT/HP) versions High-Temperature (HT) and High-Temperature / High-Pressure (HT/HP) versions High-Temperature (HT) and High-Temperature / High-Pressure (HT/HP) versions
with FKM/FPM and Kalrez
with FKM/FPM and Kalrez with FKM/FPM and Kalrez with FKM/FPM and Kalrez
®
6375 gaskets 6375 gaskets 6375 gaskets 6375 gaskets
+300°C / +572°F (single cable Ø2 mm / 0.08¨ probe only)
Ex: see supplementary operating instructions or approval certificates 2
HT and HT/HP versions with EPDM gaskets HT and HT/HP versions with EPDM gaskets HT and HT/HP versions with EPDM gaskets HT and HT/HP versions with EPDM gaskets
+250°C / +482°F (single cable Ø2 mm / 0.08¨ probe only)
Ex: see supplementary operating instructions or approval certificates 2
Pressure Pressure Pressure Pressure
Operating pressure Single cable Ø8 mm / 0.32 Single cable Ø8 mm / 0.32 Single cable Ø8 mm / 0.32 Single cable Ø8 mm / 0.32¨ probe probe probe probe
-1…40 barg / -14.5…580 psig
subject to process connection temperature and probe type used 2
High-Pressure (HP) version High-Pressure (HP) version High-Pressure (HP) version High-Pressure (HP) version
max. 300 barg / 4350 psig (single cable Ø2 mm / 0.08¨ probe only)
subject to process connection temperature and probe type used 2
All other probe types All other probe types All other probe types All other probe types
-1…100 barg / -14.5…1450 psig
subject to process connection temperature and probe type used 2
Other conditions Other conditions Other conditions Other conditions
Dielectric constant (ε
r
) Level in direct mode: Level in direct mode: Level in direct mode: Level in direct mode:
≥1.4 for coaxial probe; ≥1.6 for single and double probes
Interface in direct mode:
Interface in direct mode: Interface in direct mode: Interface in direct mode:
ε
r
(interface) >> ε
r
(level)²
Level in TBF mode: Level in TBF mode: Level in TBF mode: Level in TBF mode:
≥1.1
Vibration resistance IEC 60068-2-6 and EN 50178 (10...57 Hz: 0.075 mm / 57...150 Hz:1g)
Protection category IP 66/67 equivalent to NEMA 4X (housing) and 6P (probe)
