3.8.9 How to turn or remove the signal converter
The converter turns 360°. The converter can be removed from the process connection assembly
under process conditions.
Figure 3-44: How to turn or remove the signal converter
1 Tool: 5 mm Allen wrench (not supplied) for the lock screw on the signal converter
2 Cover for the coaxial hole on top of the process connection assembly (not supplied)
CAUTION!
If you remove the housing, put a cover on the the coaxial hole on top of the process connection
assembly.
When the housing is attached to the process connection assembly, tighten the lock screw with
the 5 mm Allen wrench 1.
