TECHNICAL DATA
8
151
OPTIFLEX 1300 C
www.krohne.com 03/2014 - 4000172306 - HB OPTIFLEX 1300 R07 en
Single probes: Dimensions in mm
Single probes: Dimensions in inches
Probes Dimensions [mm]
L min. L max. m t
Single rod Ø8 mm 1 600 2 4000 – –
Single rod Ø8 mm (segmented) 3 600 2 6000 – –
Single cable Ø2 mm 4 600 2 35000 100 Ø14
Single cable Ø4 mm 5 600 2 35000 100 Ø20
Single cable Ø8 mm 5 600 2 35000 245 6 Ø38
1 A device with this probe option must be assembled on site. For the assembly procedure, refer to "How to assemble the single rod probe
(single-piece probe)" in the Installation chapter.
2 A shorter probe length is available on request
3 A device with this probe option must be assembled on site. For the assembly procedure, refer to "How to assemble the single rod probe
(segmented probe)" in the Installation chapter.
4 1 counterweight option (Ш14Ч100 mm). No anchoring solution is available.
5 Refer to the end of this section for data about all the probe end options
6 This value is for the Ø38 mm counterweight. If you ordered the Ø12 mm counterweight: 100 mm
Probes Dimensions [inches]
L min. L max. m t
Single rod Ø0.32¨ 1 24 2 158 – –
Single rod Ø0.32¨ (segmented) 3 24 2 236 – –
Single cable Ш0.08¨ 4 24 2 1378 3.9 Ш0.6
Single cable Ш0.16¨ 5 24 2 1378 3.9 Ш0.8
Single cable Ш0.32¨ 5 24 2 1378 9.6 6 Ш1.5
1 A device with this probe option must be assembled on site. For the assembly procedure, refer to "How to assemble the single rod probe
(single-piece probe)" in the Installation chapter.
2 A shorter probe length is available on request
3 A device with this probe option must be assembled on site. For the assembly procedure, refer to "How to assemble the single rod probe
(segmented probe)" in the Installation chapter.
4 1 counterweight option (Ш0.6Ч3.9¨). No anchoring solution is available.
5 Refer to the end of this section for data about all the probe end options
6 This value is for the Ø1.5¨ counterweight. If you ordered the Ø0.5¨ counterweight: 3.9¨
