8
TECHNICAL DATA
148
OPTIFLEX 1300 C
www.krohne.com 03/2014 - 4000172306 - HB OPTIFLEX 1300 R07 en
Dimensions and weights in mm and kg
Dimensions and weights in inches and lb
Weather protection option
Figure 8-18: Weather protection option
1 Weather protection (rear view)
2 Weather protection (left side)
Dimensions [mm] Weights [kg]
a b c d
Weather
protection 208 231.5 268 1 66 2.9
1 Radius
Dimensions [inches] Weights [lb]
a b c d
Weather
protection 8.2 9.1 10.6 1 2.6 6.4
1 Radius
