TA660 User's Manual Catalyst Enterprises, Inc
90
Save Configuration You may save the test configuration for use later by clicking
Save. Assign a test file name to the configuration and click
Save.
Report Mode When Overview is checked, only test results are displayed,
however, when Detail is checked all details are listed and
explained.
Target Protocol Tests
Executing a Saved Configuration
Run Previous Configuration To run a Compliance test with a previously saved
configuration, click Load and select a configuration file.
Specify the output file name where the test results are to be saved and
click Start.
After clicking Start several messages may display, depending on the
selected test, to guide the user through the test.
Example Test
The following test (1.09) finds the addresses that are free for the
TA660 as target.
Figure 79 Compliance Test Setup
