TA660 User's Manual Catalyst Enterprises, Inc
27
Trace Statistics
Trace Statistics analysis is implemented by capturing data in memory
and then post processing it with software. The analysis software is
capable of measuring important parameters such as Minimum and
Maximum latency occurrences for any target or user defined specific
target, command utilization such as how many times an I/O write
versus I/O read occurs or, how many times memory commands occur.
Available Trace Analysis parameters that may be selected for a report
are listed on page 31.
Obtaining Trace Statistics
Click the Trace Statistics Icon on the menu bar to open the
Trace Statistics dialog box.
1. Select a Trigger Point from the Trigger On dropdown list and then
select the Trace Statistics tab to set the trace statistics options. For a
list of available choices see Trace Analysis Options on page 31.
