TA660 User's Manual
Catalyst Enterprises, Inc
46
Generate Traffic and Measure Performance
Make sure that the TA660 is in the State Analyzer & Exerciser configuration and is
operating in the Easy Mode as shown on the Main Menu bar below.
Performance Analysis with exerciser requires you to define an
exerciser program as described in Defining an Exerciser Program on
page 33.
Click the Performance Analysis Icon on the menu bar to open
the Performance Analysis dialog box as shown in Figure 42.
Figure 42 Performance Analysis with Exerciser
To perform Performance Analysis with the exerciser:
1. Define the exerciser program, such as reading or writing to a known
memory location(s).
2. Click the Performance Analysis Tab and set up the Performance
Analysis as described in Performance Analysis on page 25.
3. Click Run.
