TA660 User's Manual Catalyst Enterprises, Inc
58
Forcing an Interrupt You may force interrupts for a specific number of clocks
during the program execution by double clicking in the Int#
field for that line and then setting the interrupts in the Int#
dialog box.
Figure 52 Setting Interrupts
Setting Exerciser Options
You may set the exerciser options globally for all input program types or locally on the
Exerciser Programming window.
To set the exerciser options globally, click Exerciser on the menu
bar and select Options from the dropdown list to open the
exerciser dialog box as shown in Figure 53.
Figure 53 Exerciser Options Dialog Box
Set Options Enabled Selecting the exerciser options menu globally from the
menu bar enables the option setting for both, Master and
Target program files. When setting exerciser options from
the Exerciser Program window, only the options that are
