TA660 User's Manual Catalyst Enterprises, Inc
25
Performance Analysis
Click the Performance Analysis Icon on the menu bar to open
the Performance Analysis dialog box.
Figure 15 Easy Mode Performance Analysis Dialog Box
To perform an immediate Performance Analysis:
1. Click the down arrow next to the Performance Analysis Group list
box and select one of the four available analysis groups.
2. Select the parameters for analysis from the Available Items list.
3. Select the counters mode, Reset or Accumulate and click Run.
Reset/Accumulate With Reset selected, the measurement
counters are reset at the beginning of
each interval. With Accumulative
selected, the measurement counters
will continue to add up.
Save Settings To save the measurement setup, first select Save to open the
Save As Dialog Box, enter a new file name to save as a
*.pep file and click Save.
