TA660 User's Manual Catalyst Enterprises, Inc
84
Defining Event Patterns
1. Click the Event Patterns Tab
2. Define the Event Patterns as described in Defining Event Patterns on
page 61.
Programming the Exerciser
1. Click the Exerciser Program tab.
2. Program the Exerciser as described in Programming the Exerciser on
page 55
Defining Equations
1. Click the Equations Tab
2. Define Equations as described in Writing And Editing Analysis
Equations on page 79.
Running the Trace Project
1. After all of the configuration and programming steps have been
completed, click the Trace Statistics Tab and verify that the items
that you wish to collect statistics on are highlighted.
2. Click Run to collect trace statistics.
