TA660 User's Manual Catalyst Enterprises, Inc
138
In order to minimize the amount of writing to the event file, the commands used to modify
the event file are stored in a buffer. After all the commands to modify the event file have
been completed, the following command must be used to save and close the file.
event.Close();
“event” is the user name defined in the CEventBuilder statement.
To modify the event file the user must use the following command for each change:
event.SetField(nEventNo, nFieldIndex, strNewValue);
To read the value of each field of the event file the user must use the following command:
event.GetField(nEventNo, nFieldIndex, strValue);
“event” is the user name defined in the CEventBuilder statement.
“strNewValue” is the string value to be entered in the fields, place the desired value inside
quotes, for all fields except EVN_XFER (see table below).
“strValue” is the variable defined by the user to contain the results of the read command.
This variable must be defined as a “CString” type.
XFER type StrNewValue
StrValue
A32 XFER_A32
D32 (Data XFERs only IRDY = 0, TRDY = 0, DEVSEL = 0) XFER_D32
D32 (Data XFERs including Wait Cycles, DEVSEL = 0) XFER_D32S
MX32 (DE_Multiplex) XFER_MX32
A64 XFER_A64
D64 (Data XFERs only IRDY = 0, TRDY = 0, DEVSEL = 0) XFER_D64
D64 (Data XFERs including Wait Cycles, DEVSEL = 0) XFER_D64S
MX64 (DE_Multiplex) XFER_MX64
IDLE XFER_IDLE
Per User Defined XFER_USER
“nEventNo” is used to select which event to modify. The following table defines the valid
parameters:
EVENT NAME nEventNo
EV1 EVN_EV1
EV2 EVN_EV2
EV3 EVN_EV3
EV4 EVN_EV4
EV5 EVN_EV5
EV6 EVN_EV6
EV7 EVN_EV7
EV8 EVN_EV8
