TA660 User's Manual Catalyst Enterprises, Inc
143
Valid values for strExpression and return values for strValue.
SEQ_ALL
SEQ_ANY (Not used in SEQ_STORE)
SEQ_NONE
SEQ_EV1
SEQ_EV2
SEQ_EV3
SEQ_EV4
SEQ_EV5
SEQ_EV6
SEQ_EV7
SEQ_EV8
SEQ_NOTEV1
SEQ_NOTEV2
SEQ_NOTEV3
SEQ_NOTEV4
SEQ_NOTEV5
SEQ_NOTEV6
SEQ_NOTEV7
SEQ_NOTEV8
SEQ_EXPRESSION
SEQ_PROTOCOL
SEQ_TIMING
SEQ_EXTERNAL
If an expression is required in these fields, enclose the Boolean expression inside quotes.
For example to use the expression EV1 + EV2, the user would input “ev1+ev2”, including
the quotes, in the StrExpression field.
To change or read the ELSE IF statement use the following commands:
sequencer.SetElseStatement(nStateNo, nElseNo, FieldIndex, nNewValue);
sequencer.GetElseStatement(nStateNo, nElseNo, FieldIndex, nValue);
“sequencer” is the user name defined in the CSeqBuilder statement.
“nStateNo” defines the state number to be modified or to be read : valid parameters are
SEQ_S0 thru SEQ_S31
“nElseNo” defines the ELSE IF statement to be modified or to be read
“nFieldIndex” defines which of the 3 fields listed below to be modified.
“nValue” Discard and Then Goto must be defined as “UINT”, ELSE IF must be defined as a
“CString”.
Field Name nFieldIndex nNewValue/nValue
ELSE IF condition SEQ_ELSE_CONDITION See above
Discard SEQ_ELSE_DISCARD TRUE::FALSE
Then Goto SEQ_ELSE_THEN SEQ_S0 to SEQ_S31
