TA660 User's Manual Catalyst Enterprises, Inc
55
Programming the Exerciser
Make sure that the Exerciser Program Tab is selected on the Custom Project Dialog box
as shown in Figure 48. To program the Exerciser:
1. The Exerciser Program dialog box opens as default with one active
program line. You may add additional active program lines by
clicking Add.
Insert Program Line To insert a new program line between previously added
active program lines, position the cursor below the line
where you want to insert the new line and click the Insert
button.
2. Select a command such as MEM Write from the command
dropdown list for each active program line.
Available Exerciser Commands
Interrupt ACK
Special Cycle
I/O Read
I/O Write
MEM Read
MEM Write
CONFIG Read
CONFIG Write
MEM Read Multiple
MEM Read Line
MW & Invalidate
DAC : I/O Read
DAC : I/O Write
DAC : MEM Read
DAC : MEM Write
DAC : MEM Read Multi
DAC : MEM Read Line
DAC : MW & Invalidate
No Termination
TA660 to Transfer data as
Target without termination.
Disconnect with data TA660 to Generate Disconnect
as Target at the last data phase.
Disconnect without data Generate disconnect after the
last data phase.
Target Abort with data Generate Target Abort at the
last data phase.
Target Abort without data Generate Target Abort after the
last data phase.
