TA660 User's Manual Catalyst Enterprises, Inc
88
Executing a Compliance Device Test
Click “Start Test” from the Compliance drop down list on the menu
bar to open the Compliance Tests Configuration dialog box.
Note: Be sure that your board is not involved in running any
application program during the Compliance Test.
Figure 77 Compliance Tests Configuration Dialog Box
Click the browse button to the right of the “Found Devices” field to
have the TA660A search for all PCI devices on the bus. The software
will then display a list of found devices with the ID code and the
vendor code for each of the devices found on the bus.
1- Select the device you like to perform the test on.
2- Choose the desired tests from the “Tests List” and click Add >.
Test Description For a description of each test, click on a test and view the
test description on the bottom of the Compliance Tests
Configuration dialog box.
