TA660 User's Manual Catalyst Enterprises, Inc
78
UPDATE INTERVAL
Set the update rate between 500 us and 10 minutes by positioning the
Update Interval slider with the mouse cursor.
ANALYSIS WINDOW SETTINGS
Percent Ratio Select Based on The Greatest to
display results relative to the largest
value or Based on Clock, to display
an absolute measurement of all values.
Select *1 , *10, *20, *50 or *100 to
zoom the display scale from 100% full
scale to 1% full scale.
Reset/Accumulate With Reset selected, the measurement
counters are reset at the beginning of
each interval. With Accumulative
selected, the measurement counters
will continue to add up.
Chart Mode Choose Only Update Period to
display the default number of period
only and choose Periods and specify
number updated periods desired to see
on the display.
Show Expression Chose Report Mode and or Chart
Mode to see the result of the
equations in both report format as well
as graphical.
Defining Event Patterns
1. Click the Event Patterns Tab
2. Define the Event Patterns as described in Defining Event Patterns on
page 60.
