TA660 User's Manual Catalyst Enterprises, Inc
22
Selective Data Capture
You may refine your data capture by checking the Data Capture
Selection as Specific Addresses.
Figure 11 Capture Data At Specific Addresses Dialog Box
Selecting this option allows you to specify data capture at up to 3
address ranges with a specific associated command that is selected
from the CBE# dialog box. To open the CBE Type dialog box click
the ellipses button next to the Command edit box.
Figure 12 CBE Select Dialog Box
