TA660 User's Manual Catalyst Enterprises, Inc
13
LPT Port Setting
Your system parallel port may not necessarily be set to a Bi-
directional mode even if your system supports this mode.
Port not Configured If you continue to get a Hardware Not Detected even if
you have set the required LPT port, please check your
system setting for your parallel port.
To set the parallel port:
1. Restart your computer and during boot, press F1 key to enter Setup
(some systems may use a different key than F1, please consult your
system manual).
2. Once in setup select the Advanced, then Peripheral Configuration
and then Parallel Port Mode.
3. Select the Parallel Port to be configured. If your system supports Bi-
directional mode you must have choices for at least one of the
following:
Bi-directional, ECP or EPP, preferably Bi-directional first
then ECP and last EPP.
Note that Standard or Compatible modes are not a Bi-
directional mode.
4. When finished with the configuration press ESC to exit setup and
save the new configuration.
Supplied Card If your system does not support a Bi-directional mode of
operation or if you like to keep the system port for printer
then you may use the Bi-directional parallel card provided
with your analyzer.
