TA660 User's Manual Catalyst Enterprises, Inc
31
Trace Analysis Options
Latency Target *Number of waits due to TRDY before first data
phase
Latency Master *Number of waits due to IRDY not asserted
Latency Arbiter Number of clocks from REQ to GNT (master
board must be plugged on top of the TA660)
Efficiency Efficiency in percent for the duration of the
captured data
Target Efficiency *Number of TRDY# asserted over DEVSEL#
asserted
Master Efficiency * Number of IRDY# asserted over DEVSEL#
asserted
Throughput Mb/Sec Number of data transferred over time
Bus Utilization Number of cycles DEVSEL# asserted over time
IDLE Number of IDLE cycles
No of Data Transfer/Address *Size of data burst
Wait Number waits or wait time in percent
Int Ack Number of INT ACK
I/O *Total number of I/O Commands
I/O RD *Number of I/O Read Commands
I/O WR *Number of I/O Write Commands
Memory *Number of Memory Commands
Mem RD *Number of Memory Read
Mem WR *Number of Memory Writes
Configuration *Number of Configuration Cycles
CFG RD *Number of Configuration Read
CFG WR *Number of Configuration Write
MEM RM *Number of Memory Read Multiple
DU ADD *Number of Dual Address Commands
MEM RL *Number of Memory Read Line Commands
MEM W&I *Number of Memory Write and Invalidate
Total No of Data *Number of Data Transferred during capture
RETRY *Number of Target Retry
TABORT *Number of Target Aborts
DIS+DATA *Number of target disconnect + data
DIS-DATA *Number of target disconnect - data
MABORT *Number of Master aborts
Latency, REQ# to Data Latency time from REQ# asserted until data
transferred, including retries
DEVSEL Speed Reports Target Decode speed
* Indicates a total or number at specified address or an address range
