TA660 User's Manual Catalyst Enterprises, Inc
67
Programming the Sequencer as Text
To program the sequencer as text, click the Text button on the
Sequencer Form menu to open the text programming window as
shown in Figure 61.
Figure 61 Prototype Text Programming Window
The text programming window opens with three default prototype
states with all programmable parameters displayed in blue.
Additional States You may add unlimited additional states by clicking the
Add State button. Programmable parameters are displayed
as blue.
Maximize Display You may maximize the programming window by clicking
the Full Screen button.
To Change Parameters
1. Position the display cursor over the parameter and double click the
left mouse button to open a list box with available choices for that
parameter. See Figure 62.
2. Choose the desired parameter with the display cursor and double
click the left mouse button.
To Delete a Parameter Double click the parameter to be deleted and select delete.
Add Else If You may include Else If statements in your program by
clicking the Add Else If button. To remove the added Else
If, double click on it and choose from the open list
box.
