TA660 User's Manual Catalyst Enterprises, Inc
127
Table 3 External Signal Color Code Assignment
Signal Name Color
1 XX00 Brown
2 XX01 Red
3 XX02 Orange
4 XX03 Yellow
5 XX04 Green
6 XX05 Blue
7 XX06 Violet
8 XX07 Gray
9 XX08 White
10 XX09 Black
11 XX10 Brown
12 XX11 Red
13 XX12 Orange
14 XX13 Yellow
15 XX14 Green
16 XX15 Blue
17 GND Violet
18 GND Gray
19 GND White
20 Not Used Black
