TA660 User's Manual Catalyst Enterprises, Inc
20
Table 1 Pre-Defined Trigger Points
0 Address Triggers on specified address
1 Any Interrupt Trigger when any interrupt occurs
2 Burst Longer Triggers when the burst is longer than nnn times
3 Burst Shorter Triggers when the burst is shorter than nnn times
4 DMA Transfers Triggers when data burst is transferred
5 Data at Address Triggers on specified data at address
6 External Input Trg. Triggers on external input trigger
7 GNT# Triggers when GNT# is asserted
8 Master Abort Triggers when a master abort occurs
9
Occurrence of SERR#
or PERR#
Triggers when error SERR# or PERR# occurs
10 Protocol Error Triggers when any PCI protocol error is detected
11 REQ# Triggers when REQ# is asserted
12 Reset De-asserted Triggers when reset is de-asserted
13 Assert – De-assert Signal xxx asserted and then de-asserted nnn times
14 Asserted Signal xxx asserted for more than nnn times
15 De-assert – Assert
Signal xxx de-asserted and then asserted for more than nnn
times
16 De-asserted Signal xxx de-asserted for more than nnn times.
17 Signal Shorter Triggers when signal xxx is shorter than nnn times
18 Target Abort Triggers when a target aborts
19 Target Disconnect Triggers when a target disconnects
20 Target Retry Triggers when a target Retry occurs
21 Target Retry nnn times
Triggers when a consecutive target Retry occurs more than
nnn times
22 Target Termination Triggers on target termination, combination
23 Vendor & Device ID Triggers on Vendor & Device ID access.
